SAE 30R7 Textile Braided Low Pressure Fuel Rubber Hose

FOB Reference Price:Get Latest Price
1 Meter/Meters (Min. Order)
Supply Ability:
200000 Meter/Meters per Month
Port:
Any ports in China
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Liaoning, China (Mainland)
Brand Name:
XFY
Model Number:
3/8''~4''
Color:
Black
Material:
Synthetic rubber
Reinforcement:
High tensile synthetic texitile
Cover:
Abrasion, ozone and weather resistant rubber
Temperature:
-35℃ ~ 125℃
Certification:
ISO 9001, UL 330
Length:
50 meter ~ 100 meter
Working pressure:
250 psi/ 17.2bar
Surface:
Mill Finish /wove
Packaging & Delivery
Packaging Details
Hose in plastic woven bag, hose assembly in carton
Delivery Time
15 days

Specifications

1. We are specialized in fuel hose over 10 years.
2. The best quality and competitive price
3. Free sample

  ♦ SAE 30R7 DIN 73379-2B Low Pressure Fuel Hose



   ♦Recommended for clamped hose application on all fuel systems

   ♦Nitrile-based rube provideds exceptional resistance to a variety of ful systems

   Cover compound provides ecceptinal oil, heat, ozone and weathering resistance

   ♦ Temperature Range -35°C ~ 125°C/ -30°F ~ 257°F



♦ SAE 30R7 DIN 73379-2B Low Pressure Fuel Hose



Construction

   ♦Nitrile-based Chemigun-TM tube compound

     Two-spiral polyester reinforcement

    CSC ( Chlorosulfonated Polyethlylene) cover compound



  ♦ SAE 30R7 DIN 73379-2B Low Pressure Fuel Hose



SIZE

max OD

WP

BP

Weight

Min. Bend Radius

Max. Length

in

mm

mm

Mpa

Mpa

KG/M

mm

M/roll

1/4"

6

13.3

2.0

6.0

0.14

65

50~80

5/16"

8

14.9

2.0

6.0

0.16

75

50~80



3/8"

10

16.5

2.0

6.0

0.19

75

50~80

1/2"

13

20.6

2.0

6.0

0.26

100

50~80

5/8"

16

24.6

2.0

6.0

0.35

125

50~80

3/4"

19

29.4

2.0

6.0

0.51

150

50~80



































































 ♦ SAE 30R7 DIN 73379-2B Low Pressure Fuel Hose
